Leviton® 2-pole Commercial Grade Single Receptacle, Straight Blade, Ivory, Nema 6-20r, 250 Volts, 20 Amps

Leviton® 2-pole Commercial Grade Single Receptacle, Straight Blade, Ivory, Nema 6-20r, 250 Volts, 20 Amps

$4.22

AC Horsepower Ratings | At Rated Voltage: 2 HP^^Electrical Specifications | Dielectric Voltage: Withstands 2000V per UL498 | Current Limiting: Full Rated Current^^Environmental Specifications | Flammability: Rated V-2 per UL94 | Operating Temperature: -40°C to 60°C^^Material Specifications | Face Material: Nylon | Body Material: Nylon | Line Contacts: Brass Double Wipe .031 Thick | Terminal Screws: Brass 8-32 | Grounding Screw: Brass 8-32 | Yoke: Zinc-Plated Steel^^Mechanical Specifications | Terminal ID: Brass-Hot, Green-Ground, White-Neutral | Terminal Accom.: 14-10 AWG | Product ID: Ratings are permanently marked on device^^Product Features | Grounding: Grounding | Amperage: 20 Amp | Voltage: 250 Volt | NEMA: 6-20R | Pole: 2 | Wire: 3 | Termination: Side | Face Material: Nylon | Body Material: Nylon | Strap Material: Steel | Color: Ivory | Wallplate Not Included^^Standards and Certifications | NEMA: WD-1 & WD-6 | ANSI: C-73 | UL498: File E13399 | UL Fed Spec WC-596: File E13399 | CSA C22.2 No. 42: File 152105 | NOM: 057 | Warranty: 10 Year Limited
